Product details

The microphone reeler is available in two modifications: with 16 m and 25 m cable lengths. Other cable lengths are available on request. A professional Starquad microphone cable provides a very high EMI and RFI noise immunity and makes it possible to use the microphone reelers in the most unfavorable electromagnetic conditions, for example in proximity of lighting equipment. Cable outer diameter may be specified at the point of order.

For safety purpose, user can limit the maximum deployment length of the cable that correspond to the lowest operational position of a microphone.

Standard mounting options include grips for fixing the reeler on a 50-60 mm pipe and fixtures to install the reeler on a stage grid. Other fixtures are available on request.

• Cable length: 10, 16 or 25 m;
• Cable type: Microphone StarQuad (four isolated twisted shielded copper wires)
• Outer diameter: 3,4 mm;
• Speed: controlled, up to 0.5 m/s;
• Load: up to 2 kg;
• Positioning accuracy: +/- 10 mm;
• Connector type: XLR 3 pin, Lemo (option);
• Power supply 110-220 V AC, 24V or 48V DC (option)
• Dimension: 405 х 505 х 140 mm;
• Weight: 25 kg.
